CONTROL TECHNIQUES SP1403

0 yorum | Yorum Yap

Stok Durumu: Stokta var

0,00TL

Vergiler Hariç: 0,00TL

Ürün Kodu: CONTROL TECHNIQUES SP1403

Hızlı Bİr Bakış

ManufacturerControl TechniquesHeight (mm)322RangeUnidrive SPRange typeVariable Speed DriveApplicationHigh Performance / HVAC Fan & PumpInput PhaseThree Phase / Triphas?Input Supply Voltage380...480V ACAmp Rating (Constant Torque)4.2Power KW (Constant...

Adet − +

Manufacturer	Control Techniques
Height (mm)	322
Range	Unidrive SP
Range type	Variable Speed Drive
Application	High Performance / HVAC Fan & Pump
Input Phase	Three Phase / Triphas?
Input Supply Voltage	380...480V AC
Amp Rating (Constant Torque)	4.2
Power KW (Constant Torque)	1.5
Filter	Industrial
Normal Duty Amp	5
Power KW (Fan & Pump)	2.2

Depth (mm)	219
Width (mm)	62
Keypad	Yes
IP Rating	IP20
Logic (PNP/NPN)	Negative (NPN) / Positive (PNP)
Loop	Open / Closed
NEMA	Nema 1
Relay Outputs	1
No Analog Outputs	2
No Digital Outputs (dedicated)	3
No Analog Inputs	3
No Digital Inputs	7

CONTROL TECHNIQUES SP1403
